超高频RFID读写模块NANO-RFID打印机和手持机用-ThingMagic

产品简介：



  ThingMagic Nano是M6e 系列中体积最小的模组--仅仅1元硬币大小，是低功耗超高频RFID模块，它提供了0~27DBM的射频输出范围，而这对于内置电源驱动的    RFID打印机（battery-operated RFID-enabled printers），标签调试站（tag commissioning stations）产品认证(product authentication) 和门禁读卡器(access control readers）是非常重要，且，实现了对于近距离查找定位的特殊功能。向硬件集成商提供一个低功耗、低成本、小型化的便携式射频读写器解决方案。



ThingMagic Nano 的射频输出范围(0 dBm to +27 dBm)对于基于RFID打印机和标签调试站的读写需求是很重要的。它的表面封装为SMT生产的效率而设计，同时降低批量内嵌RFID应用程序的总成本，包括耗材认证和设备配置。



 Introduction to thingmagic nano UHF RFID module / module:



Thingmagic nano is the smallest module in the M6E series -- only 1 yuan coin size, which is a low-power UHF RFID module. It provides 0-27dbm RF output range, which is used for the product authentication of the built-in power driven RFID printers and tag commissioning stations And access control readers are very important, and realize the special function of short-range search and location. Provide a low-power, low-cost and miniaturized solution for the hardware integrator.



The RF output range of thingmagic nano (0 DBM to + 27 DBM) is very important for the reading and writing requirements of RFID printer and tag debugging station. Its surface packaging is designed for the efficiency of SMT production, while reducing the total cost of batch embedded RFID applications, including consumables certification and device configuration.
