Alta Data Technologies的PCIE4L-1553接口模块是一个多通道（1-4）、?尺寸、4通道PCI Express 1553卡，支持***的软件技术。PCI Express卡基于***进的32位1553 FPGA协议引擎AltaCore?, 通过功能丰富的应用程序编程接口AltaAPI?, 它是一个多层ANSI C和Windows.NET（MSVS 2005/08/10 C++，C#，VB.NET）体系结构。此硬件和软件包提高了系统性能并缩短了集成时间。
AltaCore-1553***符合1553B通知II和IV，所有卡都是按照的IPC 3级标准和***:2008流程制造的。卡有双功能（BC/Mon或多RT/Monitor）或全功能（BC、mRT和Mon）配置。播放和信号生成是BC操作的一部分。Alta致力于***集成，并将很乐意帮助您进行任何级别的系统开发。
可提供1553插孔连接器和AUX I/O的可选电缆组件——请参阅零件号。
信号捕获电路包含在***个通道中，用于电缆故障排除和网络安全建模。下面的示例捕获显示在我们的AltaView分析器中，或者将捕获与AltaAPI SDK（包括在内）集成在您的应用程序中：
主要功能
1-4独立、双冗余（A/B）MIL-STD-1553信道。标准半尺寸PCIe
双功能（BC/Mon或mRT/Mon）或全功能（BC/mRT/Mon
每个通道1 MB内存
可变电压1553 TX可选
全符合MIL-STD-1553B通知II/IV、MIL-STD-17601553A和Link-16
商用或工业用耐高温零件
**A/D信号捕获的一个通道–使用AltaView查看1553波形**
用于电压测量的8位、50 nSec A/D
***的32位BC、RT和Monitor FPGA设计–完整的32位内存。
BC框架/子框架/非周期性
BC、RT和Monitor的通用数据包（CDP）–完整的消息信息
***、多层AltaAPI免费提供源代码
Windows、Linux、RTOS、LabVIEW和RT
.NET托管DLL
联系工厂获取***RTOS支持
真正的硬件播放-硬件同步通道
***：20ns信号生成
比特构造–1553 PHY TX
支持RT验证测试
IRIG-B RX PAM或RX/TX PPS外部时钟
航空电子等级和RS-485离散/Clk
1760 Ext RT寻址
***自检功能和双温度传感器
1/2尺寸，4通道PCI Express 1.1
MSI和常规硬件中断支持
订货列表
| Part Number | Description |
| PCIE4L-1553-1F-T | PCI Express Interface (4 Lane) with One Channel of Dual Redundant MIL-STD-1553 with Full Function (BC/mRT and Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-2F-T | PCI Express Interface (4 Lane) with Two Channels of Dual Redundant MIL-STD-1553 with Full Function (BC/mRT and Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-3F-T | PCI Express Interface (4 Lane) with Three Channels of Dual Redundant MIL-STD-1553 with Full Function (BC/mRT and Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-4F-T | PCI Express Interface (4 Lane) with Four Channels of Dual Redundant MIL-STD-1553 with Full Function (BC/mRT and Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-1D-T | PCI Express Interface (4 Lane) with One Channel of Dual Redundant MIL-STD-1553 with Dual Function (BC/Mon or mRT/Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-2D-T | PCI Express Interface (4 Lane) with Two Channels of Dual Redundant MIL-STD-1553 with Dual Function (BC/Mon or mRT/Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-3D-T | PCI Express Interface (4 Lane) with Three Channels of Dual Redundant MIL-STD-1553 with Dual Function (BC/Mon or mRT/Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| PCIE4L-1553-4D-T | PCI Express Interface (4 Lane) with Four Channels of Dual Redundant MIL-STD-1553 with Dual Function (BC/Mon or mRT/Mon) Capability. Included: Thumb Screw SCSI I/O Connector (Must Use -T Series Mating Connector) and AltaAPI Software. |
| Capability. Included: AltaAPI Software. |
|
| Options | Example: PCIE4L-1553-4F-ABE |
| -A | AltaView SW Full Functionality Enabled |
| -B | RT Validation SW Enabled (Two Channel+ |
| -D | Direct Coupling (Price Per Channel) |
| -E | Extended Temp (-40 to 85 Indust Components) |
| -F | Conformal Coating |
| -I | Tx Inhibit (BM Function Only) |
| -N | NVRAM Write Disabled |
| -V | Variable Voltage (Price Per Channel for PCI and PCIE4L Cards Only) |
| Cables | Cable Assemblies |
| SCSI-1553-X-01-T | SCSI to 1553 Jack Connectors (X=Channel Count) |
| SCSI-1553-X-AUX01-T | SCSI to 1553 Jack Connectors with DB50 AUX I/O (X=Channel Count) |
