HYH50W户外红外热成像仪-工业仪器仪表产品栏目-AIoT库

< >

售价：面议

应用领域:

Hybrid HYH50W红外热成像仪户外热像瞄热成像

Model	Hybrid HYH50W
Detector Specifications
Type	Uncooled Vox
Resolution，pixels	640×480
Pixel size，μm	12
NETD，mk	≤ 25
Frame rate，Hz	50
Optical Specifications
Objective Lens，mm	50
Field of View（H×V），°	8.8°x6.6°
Linear Field of View（H×V），m at 100m	15.4×11.5
Magnification, ×	2.5~20
Eye Relief，mm	60
Exit pupil Diameter，mm	23
Diopter,D	-4~ +2
Detection Range，m（Target size：1.7m×0.5m，P(n)=99%）	2600
Display Specifications
Type	AMOLED
Resolution,pixels	2560×1920
Battery Power Supply
Battery	1 Built-in li-ion battery/4.4Ah/3.7V
Max. operating Time(22℃)*，h	6
External Power Supply	5V (Type C)
Physical Specifications
Wi-Fi/APP	Support (InfiRay outdoor)
Photo/Video Recorder	support
MIC	support
Bluetooth	support
Memory Capacity	64GB
IP rating	IP67
Operating Tempeture，℃	-20℃~+50℃
Weight，g	930
Dimension，mm	280×77×76
Body Material	Aluminium alloy
Connections and Compatibilities
Impact	1200g
Recommended Magnification of the Day Sight, ×	1-6
Mount	support
Remote control	support
Functions
Laser rangefinder	support（external）
Measuring Range，m	1000/2000
Measuring Angle, °	/
Measurement Accuracy	±1m
Wavelength, nm	905
Safety class for laser equipment according to IEC 60825-1:2014	3R
